What would you expect if an evil toy maker invited you and six other random third rate actors to spend a night in a campy early-nineties CGI haunted house for the chance to win a fortune? The answer is obvious: horror themed logic puzzles!

Let’s delve into 1993’s the 7th Guest (now playable almost anywhere with ScummVM), a series of puzzles barely held together by a “horror” storyline. One of the first puzzles we’ll have to solve involves a cake with skull, tombstone and plain toppings, which we will have to cut into six pieces with the same type and number of toppings.

Let’s start by getting a representation for the cake, I don’t think anyone will be surprised when we turn to our trusty matrix, with 1s being skulls, 2s tombstones and 0s plains:

(def cake [[1 2 2 1 2 1]
           [0 2 1 1 2 1]
           [0 2 2 0 1 0]
           [1 1 2 0 1 2]
           [2 2 1 0 1 2]])

For the solution, we can use numbers from 3 to 8 to represent each of the pieces, so this would be one of the multiple solutions:

(def solution [[3 8 8 8 7 6]
               [3 3 3 8 7 6]
               [4 4 3 8 7 6]
               [4 4 4 7 7 6]
               [5 5 5 5 5 6]])

As you can see each piece has 2 skulls, 2 tombstones and a plain topping. For starters, we need to get the number of each type of topping that a piece will have, something like this:

{0 1, 1 2, 2 2}

Starting from the cake and the number of pieces we want to make, here’s a way of getting this piece spec

(defn get-spec [pieces cake]
  (into {} (map #(vector (first %) (-> % last count (/ pieces)))
                (group-by identity (flatten cake)))))

Basically we group the toppings, count them and divide by the number of pieces for each, creating a hash with the result. With this spec it now becomes easier to think about how we are going to solve the puzzle. Starting from a fixed position, in each iteration we are going to add a chunk to a piece, making sure that it conforms to the spec.

For the next iteration the cake will have one less available chunk (the one we added to the piece) and the spec will reflect that it needs one less of the topping we added. Once a piece is complete, we’ll reset the spec to start creating a new piece.

The following piece of code updates all these parts. Note that we are using a map to store all the different pieces of information and moving them around, and we are merging it with the updated versions of each of them:

• The cake with the piece updated.
• The spec with one less of the taken topping
• The position in the cake we have just updated, so that in the next iteration we now where to start from

(defn update-position [pos state]
  (let [{:keys [cake piece-num spec]} state]
    (merge state {:cake (assoc-in cake pos piece-num)
                  :last-pos pos
                  :spec (update-in spec [(get-in cake pos)] dec)})))

With this the next part should be pretty familiar for us, from a position we gather all the adjacent chunks that could be added to the current piece and return a list of these new states:

(defn valid-next [{:keys [last-pos spec cake]}]
  (filter #(valid-val? (spec (get-in cake %)))
          (for [coord [[-1 0] [0 -1] [1 0] [0 1]]]
            (map + last-pos coord))))

(defn get-next-states [original-state state]
  (let [state (update-spec original-state state)]
    (map #(update-position % state) (valid-next state))))

Next up, we need a way of checking for solutions. One way would be to check that each piece conforms to the spec, however, since we are ensuring that each piece conforms while we are creating it, checking for the solution is as simple as ensuring that there are no toppings left on it:

(defn solution? [{piece-num :piece-num} state]
  (every? #(>= % piece-num) (flatten (:cake state))))

We are almost done, if you check the repo you’ll see some more functions that, given a cake and a number of pieces create the map we use to iterate and curry the solution? and get-next-states functions so that they can be used in our solvers.

I think we’ve had enough cake for one sitting, come back next time to see how our generic solvers fare when confronted with this sweet problem.
